Key Advantages
Enhanced Safety & Reliable Performance:
Powered by NCM lithium battery cells, the battery delivers excellent thermal stability and reliable performance. Compared with traditional NCM cells, NCM chemistry provides enhanced safety during long-term operation, ensuring stable power output for patient transfer applications.
Intelligent Safety & Smart Communication:
When used, the protection plate is equipped with a power supply, overload, overflow, overheat protection, automatic disconnection power under different circumstances. Support the actual time communication, the number of connections that can be made, the number of connections, the clear and clear view of the configuration.
Long-Lasting Operation & User-Friendly Control:
After charging the battery, it supports a transfer distance of 10km, and the demand for full-scale operation is high. Equipped with a large-sized LCD operation interface, clear display, convenient operation, no demand, no need to learn, and easy to use.
Specifications
|
Product Specifications |
HQ-24V2.5Ah |
Battery Type |
NCM Battery |
|
Charging Voltage |
29.4V |
Charging Current |
0.5A |
|
Discharge Current |
6A |
Cut-off Voltage |
21V |
|
Product Dimensions |
133 * 57 * 27 mm |
Cycle Life |
≥ 800 times |
|
Operating Temperature |
-20 - 55℃ |
Storage Temperature |
0 - 15℃ |
|
BMS |
Optional：CAN / RS485 / Bluetooth |
Battery Display |
/ |
|
Warranty |
2 years |
Service Life |
3 years |
Application Scenarios
1. Home care & daily transfer: Supporting safe transfers between beds, wheelchairs, toilets, and bathing areas. With long-lasting battery life and stable power output, it helps families and caregivers provide more convenient daily care.
2. Hospitals & rehabilitation centers: Designed for patient transfer and rehabilitation assistance, providing reliable operation with high-safety battery protection for intensive medical environments.
3. Elderly care facilities: Suitable for nursing homes and assisted living centers, reducing caregiver workload with dependable mobility support and intelligent battery management.
FAQ
1. Q: The battery is IPX6 waterproof. Is it safe to rinse it directly with water while showering in the bathroom?
A: Yes, it's very safe. The battery pack features a robust IPX6 waterproof design, effectively resisting powerful water jets. When used with a water dispenser for showering, you can safely rinse the device with water without worrying about water ingress or short circuits, ensuring true safety and peace of mind in showering scenarios.
2. Q: The battery supports Bluetooth wireless control. If the phone is out of power or not nearby, can it still be operated normally?
A: Yes. Bluetooth wireless control is designed to save caregivers the trouble of bending over to find buttons while near the patient. At the same time, our battery is deeply integrated with the displacement machine control box, retaining the device's physical buttons and emergency stop function. Even without a Bluetooth connection, safe and stable operation can still be performed through the device itself.
3. Q: If the power suddenly fails during use, will the patient be suspended in mid-air?
A: Absolutely not. This battery is equipped with the latest generation BMS intelligent protection board, which not only prevents over-discharge and over-current, but also works perfectly with the displacement machine's "active release function." Even in extreme power outage situations, it ensures that the equipment lands smoothly or remains locked, guaranteeing safe movement and never putting the patient in danger.
4. Q: Can the fully charged battery support a full day of patient transfer care?
A: Yes. With a rated capacity of 8Ah, the battery can support more than 10 km of transfer movement on a full charge. For most daily home care needs, such as getting up, toileting, and bathing, one full charge is sufficient for a full day of use, significantly reducing the inconvenience of frequent recharging.
5. Q: Does the battery support real-time communication, allowing family members to monitor the elderly person's usage at any time via mobile phone?
A: Yes. Through Bluetooth and IoT technology, the device can connect to terminals such as the WeChat mini program. Users can not only monitor equipment operating status in real time but also track health-related data such as heart rate and posture. Personalized settings, including lifting speed and pause duration, can also be adjusted based on individual needs. Even when family members are not nearby, they can stay connected and better support the user's safety and well-being.
