Key advantages
High-frequency Stability & Ultra-long Lifespan:
Built with premium LMO lithium battery cells, our battery packs are specifically engineered for the frequent start-stop operation of electric linear actuators. With a cycle life of over 600 cycles, they significantly reduce long-term maintenance costs while ensuring reliable performance.
Intelligent Monitoring & Safety Protection:
Supports integrated CAN communication and LCD display for real-time access to key operating parameters. Equipped with a high-precision BMS, it monitors battery status in real time and provides protection against overcharge, over-discharge, overcurrent, over-temperature, and short circuits, ensuring safe and reliable equipment operation.
Wide Operating Temperature Range & High Adaptability:
Designed to operate reliably in temperatures ranging from -20°C to 75°C, our battery packs deliver stable performance in both severe cold and scorching heat, meeting the operational needs of complex working conditions around the world.
Specifications
|
Product Specifications |
HQ-22.2V2Ah |
Battery Type |
LMO Battery |
|
Charging Voltage |
25.2V |
Charging Current |
1A |
|
Discharge Current |
5A |
Cut-off Voltage |
18V |
|
Product Dimensions |
134 * 56 * 30 mm |
Cycle Life |
≥ 600 times |
|
Operating Temperature |
-20 - 75℃ |
Storage Temperature |
0 - 15℃ |
|
BMS |
Optional：CAN / RS485 / Bluetooth |
Battery Display |
/ |
|
Warranty |
2 years |
Service Life |
3 years |
Application Scenarios
1. Industrial automation: Widely used in the opening and closing of dampers and gates in metallurgy, mining, power and coal industries, as well as material loading and unloading and flow control, providing stable and reliable power.
2. Precision agriculture & feeding systems: Precise control of the discharge gate opening and closing on the mixing and feeding vehicle improves mixing accuracy and operational consistency, helping farmers achieve precise cost reduction.
3. Medical & home care equipment: Provides quiet and smooth lifting support for electric sofas, nursing beds, turning beds and lifting platforms, enhancing user comfort.
4. Multi-field precision transmission: perfectly adapted to automotive ventilation window opening, stage machinery lifting, sewage treatment equipment, and photovoltaic new energy tracking systems, etc.
FAQ
1. Q: Will low temperatures make it difficult for the electric linear actuator to start?
A: Our batteries support operation in a wide temperature range of -20℃. However, in extremely cold environments, ordinary grease may thicken, leading to increased resistance. We recommend using a dedicated low-temperature grease for the actuator in low-temperature conditions to ensure smooth start-up.
2. Q: Is this battery compatible with electric linear actuators using self-locking lead screws?
A: Absolutely. Our battery provides stable and continuous power output, making it fully compatible with self-locking lead screw actuators. It ensures the actuator remains securely in position when power is removed, preventing unintended movement or drift.
3. Q: If the actuator frequently triggers overload protection during operation, does it mean there's a problem with the battery?
A: Not necessarily. Overload protection is typically caused by excessive loads, mechanical jamming, or inadequate lubrication. However, an aging battery or increased internal resistance can also result in a sudden voltage drop that may activate the protection system. Our intelligent BMS continuously monitors battery performance and provides comprehensive protection. We recommend inspecting both the battery and the actuator's mechanical components to identify the root cause.
4. Q: Can the LCD display and CAN communication protocol be customized?
A: Yes. We offer comprehensive software customization services, including LCD user interface design, multilingual display options, and CAN communication protocol customization, ensuring seamless integration with your control system.
