Key Advantages
Huaqian's Self-developed LMO Series:
The battery provides stable performance even in cold winter conditions, ensuring reliable startup at low temperatures. The plug-in design is also convenient, and elderly people who travel independently can operate it easily.
Larger Capacity, More Stable Output & Longer Range:
A single charge provides a reliable range of distance, so you don't have to worry about mileage when running errands, visiting relatives and friends, or taking a walk in the park. The battery is also easy to install. It's ready to use right out of the box, no hassle.
Intelligent BMS Management and Connectivity:
Internally installed BMS intelligent protection system, equipped with features, radiation, flow, short path and temperature different protection functions, ensuring battery safety design operation. Supports CAN wire connection, can operate the machine at the time of operation, has improved high and low temperature operating performance, and can be operated under various conditions.
Specifications
|
Product Specifications |
HQ-24V12Ah (Optional: 24V6Ah,24V7.5Ah, 24V20Ah) |
Battery Type |
NCM/LMO Battery |
|
Charging Voltage |
29.4V |
Charging Current |
3A |
|
Discharge Current |
12A |
Cut-off Voltage |
21V |
|
Product Dimensions |
53 * 205 * 220 mm |
Cycle Life |
≥ 650 times |
|
Operating Temperature |
-10 - 55℃ |
Storage Temperature |
0 - 15℃ |
|
BMS |
Optional：CAN / RS485 / Bluetooth |
Battery Display |
/ |
|
Warranty |
2 years |
Service Life |
3 years |
Application Scenarios
1. Home & community mobility: Designed for daily mobility needs, our battery solutions support electric wheelchair users in residential areas, communities, parks, shopping centers, and family activities, providing reliable power for independent and convenient movement.
2. Healthcare & assisted mobility: Widely used in hospitals, rehabilitation centers, nursing facilities, and home care environments, the batteries provide safe and stable energy support for wheelchairs used in patient care, rehabilitation, and assisted transportation.
3. Travel & air transportation: Featuring a removable battery design and compliance with relevant air travel requirements, our solutions make battery removal, transportation, and installation easier, enabling wheelchair users to enjoy greater freedom during flights, tourism, and long-distance travel.
4. Public & accessible transportation spaces: Suitable for airports, commercial facilities, and public mobility environments, our batteries support frequent daily use while helping users move more confidently across different locations.
FAQ
1. Q: What type of battery does an electric wheelchair typically use?
A: Most electric wheelchairs nowadays use lithium-ion or LiFePO4 batteries, which are much lighter, longer-lasting, and more efficient than the old-fashioned lead-acid batteries, making them much easier to push and load.
2. Q: Are electric wheelchair batteries safe? Will they catch fire?
A: They are very safe and will not catch fire. The battery has a built-in intelligent BMS management system that will automatically cut off power in case of overcharging, over-discharging, overcurrent, short circuit, or overheating. It is very safe for daily use.
3. Q: Can the battery of an electric wheelchair be replaced if it is damaged?
A: Yes, most electric wheelchair batteries are designed to be detachable, making replacement and maintenance very convenient without having to send the entire wheelchair for repair.
4. Q: Can the battery of an electric wheelchair be used in the rain? Will water get in?
A: Yes, it can be used. The battery itself has a certain degree of waterproof and dustproof capability. Light rain or splashes of water on the road are fine, but try to avoid prolonged exposure to heavy rain or immersion in water.
5. Q: What safety certifications are available for electric wheelchair batteries?
A: Our products support international certifications such as UN38.3, MSDS, CE, RoHS, UL, and IEC62133. They can be flexibly configured according to different export regions, ensuring quality.
