Key Advantages
High-Rate Performance & Advanced Thermal Management:
Designed with high-performance NCM lithium cells and a low internal resistance structure, the battery delivers powerful high-current discharge capability with excellent energy efficiency. Optimized thermal management design effectively reduces heat accumulation during high-load operation, ensuring stable power output and reliable performance throughout demanding flights.
Enhanced Safety with Advanced NCM Battery Technology:
Built with premium NCM battery cells and an intelligent BMS protection system, the battery provides multi-layer safety protection against over-charge, over-discharge, over-current, overheating, and short circuits. Advanced cell management technology helps minimize thermal risks and ensures safer, more reliable operation during high-performance flights.
Intelligent Management & Long Cycle Life:
Equipped with an intelligent balancing BMS system, the battery continuously monitors voltage, temperature, current, and cell consistency while automatically balancing individual cells for optimized performance. With up to 500 cycles of service life under proper operating conditions, it delivers stable power output and long-term reliability for various aerial applications.
Specifications
|
Product Specifications |
HQ-22.2V3Ah (Optional:22.2V 5Ah ) |
Battery Type |
NCM Battery |
|
Charging Voltage |
25.2V |
Charging Current |
3A |
|
Discharge Current |
60A |
Cut-off Voltage |
18V |
|
Product Dimensions |
236 * 65 * 38 mm |
Cycle Life |
≥ 500 times |
|
Operating Temperature |
-20 - 55℃ |
Storage Temperature |
0 - 15℃ |
|
BMS |
Optional：CAN / RS485 / Bluetooth |
Battery Display |
/ |
|
Warranty |
2 years |
Service Life |
3 years |
Application Scenarios
1. Suitable for High-Performance Flight Equipment Across Multiple Industries : Designed for racing RC aircraft, outdoor exploration equipment, underwater RC vehicles, recreational models, and professional UAV platforms. With configurable high-rate cell solutions, the battery delivers stable high-power output and reliable performance under high-speed maneuvering and demanding outdoor conditions.
2. Designed for the Rapidly Growing Low-Altitude and Specialized UAV Market : With the rapid development of UAV platforms and low-altitude applications, the demand for high-power, lightweight, and high-safety energy solutions continues to grow. This high-rate semi-solid lithium battery is designed to support advanced aircraft and UAV platforms with enhanced power response, safety, and operational reliability.
FAQ
1. Q: Are RC lithium batteries safe? Is there a risk of explosion?
A: Safety is a top priority in our battery design. Each battery is equipped with a BMS that provides protection against overcharge, over-discharge, overcurrent, short circuits, and overheating. If any abnormal condition is detected, the system automatically triggers protection measures or warning functions.
2. Q: What certifications are available? Can the batteries be exported internationally?
A: Yes. Depending on the destination market, our products can be supplied with international certifications such as UN38.3, MSDS, CE, RoHS, and IEC 62133, ensuring compliance with international transportation and regulatory requirements for both air and sea shipment.
3. Q: Is battery heating during charging normal? What temperature is considered abnormal?
A: A slight temperature increase during charging is normal. However, charging should be stopped if the battery surface temperature exceeds 50°C. During discharge, operation should be suspended if the battery surface temperature exceeds 70°C, and the battery should be allowed to cool to room temperature before continued use. The recommended charging ambient temperature range is 0°C to 45°C.
