Key Advantages
Continuous Operation & Cost Efficiency:
Supports opportunity charging, allowing for quick top-ups during loading/unloading or driver shift changes to minimize downtime and maximize equipment utilization. With a cycle life of 1,500 to 3,000 cycles, three to five times that of lead-acid batteries, it significantly reduces long-term replacement costs.
Monitor Battery Status Anytime & Anywhere:
With CAN and Bluetooth communication support, key battery information including remaining capacity, temperature, and health status can be monitored in real time. No need for manual inspections under the vehicle, saving time and improving maintenance efficiency.
Reliable Performance In Extreme Environments:
From northern cold regions to southern hot climates, and from cold storage facilities to high-temperature warehouses, our batteries deliver stable output across a wide temperature range of -20°C to 60°C. Designed for multi-region applications, they provide dependable performance in diverse working conditions.
Specifications
|
Product Specifications |
HQ-48V100Ah (Optional:24V100Ah, 51.2V280Ah, 72V100Ah ) |
Battery Type |
LiFePO4 Battery |
|
Charging Voltage |
57.6V |
Charging Current |
50A |
|
Discharge Current |
100A |
Cut-off Voltage |
45V |
|
Product Dimensions |
520 * 320 * 220 mm |
Cycle Life |
≥ 2,000 times |
|
Operating Temperature |
-20 - 60℃ |
Storage Temperature |
-10 - 45℃ |
|
BMS |
Optional：CAN / RS485 / Bluetooth |
Battery Display |
/ |
|
Warranty |
2 years |
Service Life |
5 years |
Application Scenarios
1. High-intensity, high-frequency operation: For automated warehouses operating around the clock, batteries cannot be a bottleneck. High cycle life and fast charging are essential. Quickly replenishing power during downtime minimizes downtime, maximizes battery replacement cycles, and significantly reduces overall costs.
2. Reliable performance in low-temperature environments: For northern winters and cold chain warehouses, temperature is one of the biggest challenges for battery performance. Low-temperature starting capability is a critical requirement. Our optimized lithium batteries deliver reliable startup and stable output even at -20°C, ensuring equipment keeps running without delays caused by cold conditions.
3. Narrow-aisle operations: Every inch of space matters in confined working environments. Thanks to higher energy density, lithium batteries provide the same amount of power in a smaller and lighter package, making handling easier while improving vehicle maneuverability and operational flexibility.
4. Cost-sensitive applications: Traditional lead-acid batteries are still used by some small and medium-sized enterprises due to their low initial purchase cost, but their higher maintenance costs and shorter lifespan need to be weighed. Lithium-ion batteries have lower maintenance costs and longer cycle life.
FAQ
1. Q : What are the advantages of lithium-ion forklift batteries compared to lead-acid batteries?
A : The advantages are straightforward, faster charging, longer lifespan, no maintenance required, and lower electricity costs. For the same task, a lead-acid battery takes 8 hours to charge, while a lithium-ion battery can be fully charged in 2-3 hours; lead-acid batteries need to be replaced every two years, while lithium-ion batteries can last five to eight years; no need to add water, adjust the acid, or perform periodic balancing, just plug it in and use, saving you time and effort.
2. Q : Do lithium-ion forklift batteries require maintenance?
A : No. They are completely maintenance-free, requiring no water addition, no equalization charging, and no acid level checks.
3. Q : Are lithium-ion forklift batteries safe?
A : Rest assured, safety is a top priority. They use LiFePO4 cells, which have excellent thermal stability and are less prone to catching fire. Furthermore, the intelligent BMS system monitors the entire process, automatically protecting against overcharging, over-discharging, short circuits, overcurrent, and abnormal temperatures.
4. Q : Can lithium-ion forklift batteries be used in cold storage environments?
A : Yes. Our standard lithium-ion forklift batteries already deliver excellent performance under normal temperature conditions. For cold storage or freezer applications, an optional low-temperature heating system is available to ensure reliable startup and operation even in environments as low as -20°C.
5. Q : What certifications are available?
A : Products can be customized to meet export regions and customer needs, supporting international certifications such as UN38.3, MSDS, CE, RoHS, UL, and IEC62619. Whether for domestic sales or export, complete qualifications ensure worry-free inspection.
